| Camera |
| Sensor |
1/2.8", 3.0 megapixel, progressive scan, CMOS |
| Min. Illumination |
Colour: 0.003 Lux (F1.7, AGC ON)
0 Lux with IR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| Shutter |
Auto/Manual, 1 ~ 1/100000s |
| WDR |
120dB |
| S/N |
>52dB |
| Lens |
| Lens type |
5 ~ 100mm, AF automatic focusing and motorized zoom lens |
| Optical Zoom |
20 |
| Iris |
Fixed; F1.7 ~ F2.8 |
| Angle of View (H) |
51.70° ~ 3.85° |
| Angle of View (V) |
30.49° ~ 2.16° |
| Angle of View (O) |
63.60° ~ 4.54° |
| DORI |
| DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
| 5 |
77.6 (254.5ft) |
31.0 (101.8ft) |
15.5 (50.9ft) |
7.8 (25.5ft) |
| 100 |
1551.7 (5091.0ft) |
620.7 (2036.4ft) |
310.3 (1018.2ft) |
155.2 (509.1ft) |
| Illuminator |
| IR Range |
Up to 100m (328 ft) IR range |
| Wavelength |
850nm |
| IR On/Off Control |
Auto/Manual |
| Video |
| Video Compression |
H.265, H.264, MJPEG |
| Frame Rate |
Main Stream: 3MP (2304*1296), Max 30fps;
Sub Stream: 720P (1280*720), Max 30fps;
Third Stream: D1 (720*576), Max 30fps; |
| Video Bit Rate |
128 Kbps~16 Mbps |
| ROI |
Support |
| Video Stream |
Triple streams |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
24 areas, up to 4 areas per scene |
| Image |
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction |
2D/3D DNR |
| Smart IR |
Support |
| Flip |
Normal/Flip Vertical/Flip Horizontal/180° |
| HLC |
Support |
| BLC |
Support |
| Defog |
Digital Defog |
| Events |
| Basic Detection |
Motion detection, Tampering Alarm |
| Auto Tracking |
Support |
| General Function |
Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Storage |
| Edge Storage |
Micro SD, up to 256 GB |
| Network Storage |
ANR, NAS(NFS) |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS |
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and common user |
| Security |
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Client |
Uniarch Client
Uniarch app |
| Web Browser |
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above |
| Pan & Tilt |
| Pan Range |
360° (endless) |
| Pan Speed |
0.1°/s ~ 80°/s |
| Preset speed: 80°/s |
| Tilt Range |
–15° ~ 90° (auto reverse) |
| Tilt Speed |
0.1°/s ~ 80°/s |
| Preset speed: 80°/s |
| Number of Presets |
1024 |
| Preset Patrol |
16 patrols, up to 64 presets for each patrol |
| Route Patrol |
16 patrols, up to 32 actions for each patrol |
| Recorded Patrol |
16 patrols, up to 128 actions for each patrol |
| Patrol Stay Time |
15s ~ 1800s |
| Preset Image Freeze |
N/A |
| Home Position |
Support |
| Interface |
| Audio I/O |
N/A |
| Alarm I/O |
N/A |
| Serial Port |
N/A |
| Built-in Mic |
N/A |
| Built-in Speaker |
N/A |
| Wi-Fi |
N/A |
| Network |
1 * RJ45 10M/100M Base-TX Ethernet |
| Video Output |
N/A |
| General |
| Power |
DC12V (±25%), PoE+(IEEE 802.3at) |
| Power consumption: MAX 20W |
| Power Interface |
Ø 5.5mm coaxial power plug |
| Dimensions (Ø x H) |
Ø162 x 293mm (Ø6.4” x 11.5”) |
| Weight |
1.79kg (3.95lb) |
| Working Environment |
-40℃ ~ 65℃ (-40°F ~ 149°F)，Humidity: ≤95% RH (non-condensing) |
| Storage Environment |
-40℃ ~ 70℃ (-40°F ~ 158°F)，Humidity: ≤95% RH (non-condensing) |
| Surge Protection |
6KV |
| Reset Button |
Support |
| Protection |
Ingression protection: IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) |
